Key Features



• X-PRO Hawk 150 is equipped with an industry standard 5-Speed Manual Transmission, which is much better than the rotary type transmission and keeps the rider in full control of the Dirt Bike.
• Comes with 149cc 4-Stroke Engine that has a 55 MPH speed capability. The 4-Stroke engine ensures that no confusing fluid mixing will be required, just gas it up and start riding!
• The upgraded kick start on the DB-W021 Dirt Bike makes for quicker and simpler starting.
• CDI ignition system puts out a defined amount of spark which provides for a faster and stronger response which creates an all around reliable bike.
• 19" Front and 16" Rear big Tires are great for speed and traction making them a perfect tire to ride off road with. You can push the envelope of your 149cc Dirt Bikes with these.
• Adjustable Rear Mono Shock provides extra comfort while riding on rough terrain. It will keep you safe while taking your 149cc Dirt Bike to its limits.
• Upgraded Front and Rear Hydraulic Disc Brakes are great because they allow the bike to stop much quicker than other types of brakes which makes it very safe for you to ride.
• The handlebars, foot pegs, and triple tree are both manufactured in aluminum. This material creates a aerodynamic and lightweight dirt bike, which is perfect for full rider control and maneuvering.
• The Performance Aluminum Exhaust pipe included on DB-W021 is specially designed to look stylish and improve performance.
• Heavy Duty Chain and Sprocket. The chain is manufactured to be very heavy duty and durable. The high performance sprocket works with the durable chain for a very reliable pit bike.
• 32" seat height is an optimal height for riders of all ages.
• Some Assembly Required.





Specifications



Model Number	DB-W021
Engine/Drive Train
Engine	149cc, 4 stroke
Cylinder Arrangement	Single
Horsepower(hp)	12.92HP/8500rpm
Max Torque	10.0N.m/6500rpm
Cooling System	Air Cooled
Transmission	Manual 5-Speed
Final Drive	Chain Drive
Start System	Kick
Ignition	CDI
Max Speed (MPH)	55+ (Depending on Riders Weight and Road Conditions)
Frame /Body/ Suspension / Brakes
Front Suspension	Double shocks
Rear Suspension	Single shock
Front Brakes	Hydraulic Disc
Rear Brakes	Hydraulic Disc
Front Tires	70/100-19
Rear Tires	90/100-16
Capacities / Dimensions
Weight Capacity (lbs)	265
Net Weight (lbs)	220
Gross Weight (lbs)	245
Overall Length	76"
Overall Width	39"
Overall Height	47"
Seat Height	32"
Wheelbase	52"
Ground Clearance	9.05"
Gas Tank Capacity (gal)	1.56
Safety / Control
Engine Kill Switch	Yes
Foot Brake	Yes
Others
Tool Kit	Yes
